Neon – Top bend, 10 x 10 mm, 9.6W, 3000K@528Lm/m, free-cut
| Series code: | VL-OSI1010-W |
| Bend direction: | Top-bend |
| Volt: | 24V DC |
| Power: | 9.6W/m (2.93 W/ft) |
| Lumens: | 528 lm/m (160 lm/ft) @3000K, CRI90+ |
| Efficacy: | 55 lm/W @3000K, CRI90+ |
| CRI: | >90 (custom on request) |
| CCT: | 2700K / 3000K / 3500K / 4000K (custom on request) |
| Distribution: | Opal / 120° |
| Drivers/Dimming: | 0-10V; DALI, PWM, On/Off |
| IP/IK protection: | IP68 / IK06 |
| Housing: | Premium silicone in white |
| Dimension: | W: 10 mm (0.3 in), H: 10 mm (0.3 in); Max run: 5 m (16.4 ft) |
| Environment: | Suitable for dry or damp locations or wet location |
| Mounting: | Surface, Recess or Ceiling |
| Approvals: | UL, CE, ROHS, REACH |
| Warranty: | 5 years, limited |
· IP68 protection allowing immersion in water up 3m
· Resistance to water pressure ensuring reliable performance
· Exceptional corrosion resistance for long-term durability
· Uniform output with consistent brightness and color stability
· Flexibility and free-cutting for various configurations
· Pool lane markers
· Underwater seating areas
· Fountain vertical jets
· Aquarium tunnel floors
